Sophisticated lens design for 360° angle imaging

The GS-1 incorporates a unique one-of-a-kind multimirror prism lens designed specifically for this system. Sixteen surfaces capture 360 degrees in one smooth measurement sequence.

The NIDEK multimirror prism lens was developed by optimizing each surface for the perfect angle (The patent for 360-degree angle imaging with multimirror prism lens is pending.)

Intelligent “Angle Detection”

Automated Angle Detection provides guidance for capturing the iridocorneal angle. Through diligent research, NIDEK developed Angle Detection that can recognize angles regardless of eye color.

Introducing innovative “Stitching”

The GS-1 composes linear and circular images of iridocorneal angle structures when the entire 360 degrees are captured.

A picture is worth a thousand words

Focus depth

Each area is automatically captured in 17 different foci, enabling versatile approaches to the angle. (Up to 15 images per area can be saved.)

Resolution

High resolution images allow detailed observation of the angle including PAS (peripheral anterior synechia), pigmentation, neovascular vessels, and MIGS devices.

Data storage and report export

Data saving without an external PC connection enhances clinical efficiency and patient management. Different from classic gonioscopy, diagnosis can be performed based on the acquired images rather than at the time of assessment. Images can be easily shared at conferences and used for patient education.
